SR & Wall speaker
SURROUND SPEAKER
Excellent sound performance suitable for broadcasting as well as music purposes
- Suitable to install in a high quality environment as it has elegant appearance and robust enclosure
- Black and white available
- High-class restaurants, coffee shops, malls, schools, community centers, churches, etc.
- Built-in 2 WAY speaker and network producing excellent sound quality
| Model | SJS-550SM | |
| Type | 5 inch, 2 Way, 2 Speaker system | |
| Power(rated) | 50W | |
| Frequency Range | 60Hz ~ 18KHz | |
| Impedance | 8Ω, 200Ω(50W), 330Ω(30W) | |
| SPL(1W/1M) | 98±2dB | |
| Materials | ABS Resin/Robust grill | |
| Net weight | 2.0Kg | |
| Dimensions | 245(W) x 150(H) x 160(D)mm | |
| Max power | 100W | |
WALL SPEAKER
Enhance from tone quality to best by using KS speaker
- Easy to attach to a wall.
- Built in a matching transformer
- Well fit with the surrounding environment.
- Input voltage : 100V line
Specification
| Model | SJC-3WB | SJC-5WB | SJC-10WB |
| Input Power(Rated) | 3W | 5W | 10W |
| Frequency | 150Hz-14KHz | ||
| Impedance | 3.3KΩ(3W), 5KΩ(2W) | 2KΩ(5W), 3.3KΩ(3W) | 1KΩ(10W), 2KΩ(5W) |
| SPL(1W/1M) | 93dB | ||
| Materials | Wood | ||
| Color | Brown | ||
| Weight | 1.35Kg | 1.48Kg | 1.52Kg |
| Dimensions | 290 x 100 x 210mm | ||
Specification
Injected cases well harmonious with other structures.
| Model | SJC-10WA |
| IInput Power(Rated) | 10W |
| Frequency | 130Hz-15KHz |
| Impedance | COM. 1KΩ(10W), 2KΩ(5W), 3.3KΩ(3W) |
| SPL(1W/1M) | 93±2dB |
| Materials | ABS resin/steel front grille |
| Net Weight | 1.9Kg |
| Dimensions(mm) | 240x345x100mm |
Specification
Improved durability by using solid structure and materials
| Model | SJC-P103N | SJC-P110N |
| Input Power(Rated) | 3W | 10W |
| Frequency | 130Hz-12KHz | |
| Impedance | 3.3KΩ(3W), 5KΩ(2W) | 1KΩ(10W), 2KΩ(5W) |
| SPL(1w.1m) | 88dB | 90dB |
| Materials | ABS Resin | |
| Color | White | |
| Weight | 690g | 1.02kg |
| Dimensions(mm) | 220 X 270 X 87/55(D)mm | |
